Hiring a thermal imaging camera can offer many advantages, especially for short-term projects, experimental endeavours, or specific medical requirements. Depending on the context, renting a camera can be the most optimal and cost-effective solution. At Thermal Vision Research, we prioritise tailoring solutions that perfectly align with your unique needs. If you’re uncertain about the ideal approach for your project, we welcome you to reach out for a consultation, as we’re dedicated to helping you make the best-informed decision. We are always here to help so contact us anytime.

T: 07973403819
E: matthew@thermalvisionresearch.co.uk

Also, follow us on Instagram

Some examples of completed projects suing are systems.

Images and video created using the Teledyne FLIR X8500 and RS6780

ENTROPY The traces we leave behind.

Films. Dance is a cultural and global platform for dance.

Produced by Jacob Jonas The Company, a creative studio that intersects dance across disciplines through nontraditional collaborations and community building.

Zone of Interest FESTIVAL DE CANNES GRAND PRIX 2023

Watch the Film4-backed The Zone of Interest trailer from writer/director Jonathan Glazer. The loose adaptation of Martin Amis’s 2014 novel of the same name stars Christian Friedel as Rudolf Hoss, an Auschwitz commandant, and Sandra Hüller as Hedwig Höss, his wife and accomplice. The film examines the ordinary existence of individuals complicit in unforgivable acts as it watches them strive to build a dream life for their family in a house and garden next to the concentration camp. Also starring Max Beck, Ralph Herforth, Stephanie Petrowitz, Sascha Maaz, Marie Rosa Tietjen, and Lilli Falk.

Filmed using FLIR Infrared  In my opinion, one of the best music videos ever created in thermal

Thirty Seconds To Mars and Travis Scott perform “Walk On Water” on the 2017 MTV Video Music Awards on August 27, 2017, courtesy of MTV. “It took a village to be able to bring this idea to life. A very large village. When you do a show like the MTV Video Music Awards you have an opportunity to explore and experiment, to revisit the past or to push towards the future. We knew we wanted to do something that hadn’t been done before. Playing in total darkness, capturing our performance via thermal signal and doing it live was complex, challenging and seemingly impossible but with the help of a very patient MTV and an enthusiastic team of creative dreamers we accomplished our goal. Working with Vatche and the incredible team at FLIR has been inspiring and an absolute pleasure.” – Jared Leto

Two specific systems for TV, Film and the Natural World

Teledyne FLIR Research Grade sensor for HD and long range video.

RS6780sc - £895.00+vat per day

The FLIR RS6780 offers advanced detector, triggering, and synchronization capabilities in an environmentally protected package, making it easy to configure and integrate for successful data acquisition in the most demanding R&D applications. With a three-position motorized filter wheel and continuous metric zoom (CZ) lens, the RS6780 records sharply focused, high-quality thermal images in long-range and tracking applications. The standard 50-250 mm CZ lens can be factory-calibrated for temperature and radiance measurements, allowing researchers to use the radiometric camera system without sacrificing the flexibility of the optics platform.

Insurance value £165k+vat
Key System information
  • Spectral Range 3 – 5.0 µm
  • 640 x 512 sensor
  • Framerate 125Hz – full frame
  • Motor Focus
  • Calibration -20°C to +2000°C
View Datasheet

X8500sc - £595.00+vat per day

The FLIR X8500sc is a highly sensitive, high-speed, high definition MWIR camera designed for scientists, researchers, and engineers. It has all the features needed for research and science: from on-camera RAM/SSD recording to a four-position motorized flter wheel. Plus, by combining HD resolution with high-speed frame rates, the X8500sc allows researchers to fully image the scene and stop motion on high-speed events – whether they’re in the lab or on the test range.

Insurance value £140k+vat
Key System information
  • Spectral Range 1.5 – 5.0µm
  • 1280 x 1024 sensor
  • Framerate 181Hz – Full frame
    1280 x 1024 – 181Hz
    1280 x 512   –  352Hz
    1280 x 4 –        5362.32Hz
  • Manual Focus
  • Calibration -20°C to +2000°C
  • 10° Lens (f =50 mm)
View Field of View detailsView Datasheet

System mounting and setup

Teledyne FLIR Research Grade sensor for HD and long range video.

All cameras come with standard tripod mounting (2 x ¼ in. -20, 1 x 3/8 in) on the underside, which allows you to fix your existing equipment without needing unique or custom plates.

All systems use the same power setup, 24 VDC (< 50 W steady state), and we can provide custom cables for easy integration into portable power packs.

The RS platform comes in weatherproof housing, and we also have housing for the X and A series cameras if required.

X and A Series cameras have manually focusable optics but can be motorised with various industry-standard focus wheel systems.

Integration into larger systems is possible via multifunction outputs on all included cameras—SDI, Sync, Trigger, HDMI, Record Start—allowing for remote filming via Wired dolly or heavy-lift drones.

The software can be provided on a 30-day trial or purchased. Full training can be supplied for both pre- and post-production.

Images and video showing the beauty in the natural world when using Infrared.

Images and video created using the Teledyne FLIR X8500 and RS6780

Giraffe 100m distance

Giraffe 100m distance

Bushback Jumping 100m distance

Giraffe 100m distance

Bird Feeding time

The beauty of dance

Accessories for the FLIR X8500

We can also provide additional accessories for hire - please contact us to detail your specific requirments.
Target 1.2km away from the camera.
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.

P/N: T300585
Lens 3.0–5.0 µm, 5x microscope, FPO Manual Bayonet - £95.00+vat per day.

Designed for closeup applications.
Insurance value £15k+vat
View Datasheet

P/N: 4219797
Lens, 3-5 um, 3X microscope, f/2.5 FPO Manual Bayonet - £95.00+vat per day.

Designed for closeup applications
Insurance value £6k+vat
View Datasheet

P/N: T300385
Lens 3–5 um Macro f/2.5 MW FPO Manual Bayonett - £95.00+vat per day.

Designed for closeup work.
Insurance value £6k+vat
View Datasheet

P/N: 4215504
Lens 3-5 um 200 mm f/2.5 FPO Manual Bayonet - £95.00+vat per day.

Long distance lens
Insurance value £6k+vat
View Datasheet

P/N: 4215502
Lens 3-5 um 100 mm f/2.5 FPO Manual Bayonet - £95.00+vat per day.

Long distance lens
Insurance value £6k+vat
View Datasheet

P/N: 4215425
Lens 3-5 um 25 mm f/2.5 FPO Manual Bayonet - £95.00+vat per day.

Standard filed of view
Insurance value £6k+vat
View Datasheet

P/N: 4215423
Lens 3-5 um 17 mm f/2.5 FPO Manual Bayonet - £95.00+vat per day.

Wide angle lens
Insurance value £6k+vat
View Datasheet
Infrared

Also, check out our Infrared RD Handbook.

Click to view….

Infrared cameras allow you to make non-contact measurements of an object’s temperature for data acquisition, analysis, and reporting. They have become indispensable tools for all kinds of research and development projects, and there are many types of cameras with specific features suited to science and research applications.

To help you choose a thermal imaging (Infrared) camera that meets all your requirements, FLIR has compiled a list of the seven things you need to know before buying. This list will help you narrow down your options and point you in the right direction for your ultimate camera selection.

Point #1: What temperatures are you expecting to measure?

Typically, the goal of using an Infrared camera is to measure temperature changes on your object of interest. Two things you should consider when measuring temperature are the temperature range of your object and the temperature resolution you wish to achieve. Answering these two questions will help you determine which types
of infrared cameras and detectors are best suited for your application.

Download the guide to get the complete list.
