FLIR A70 Research & Development Kits are affordable, ready-to-use solutions for thermal imaging analysis in proof-of-concept electronics testing and R&D applications. Providing thousands of temperature measurement points, users can eliminate thermal guesswork, reduce product development time, and increase product efficiency and reliability.

• Spectral Range 7.5 – 14 µm
• 640 x 480 sensor
• Framerate 30Hz
• Manual Focus
• Calibration -40°C to +1000°C
• 51° Lens (f=8.2 mm)

FLIR A700 Science Kits offer researchers and engineers a streamlined solution for accurate temperature measurement. Simplified yet robust connections help you set up and start testing quickly; then easily view, acquire, and analyze data.

• Spectral Range 7.5 – 14 µm
• 640 x 480 sensor
• Framerate 30Hz
• Manual and motor Focus
• Calibration -40°C to +2000°C
• 24° Lens (f=17 mm) with Case
  2x Macro lens

The FLIR A6750 MWIR camera offers short exposure times and high-speed windowed frame rates, making it an ideal choice for recording rapid thermal events and fast-moving targets. Freeze motion or achieve accurate temperature measurements on moving subjects, and perform a variety of non-destructive testing with this cooled InSb camera.

The FLIR X8500sc is a highly sensitive, high-speed, high definition MWIR camera designed for scientists, researchers, and engineers. It has all the features needed for research and science: from on-camera RAM/SSD recording to a four-position motorized flter wheel. Plus, by combining HD resolution with high-speed frame rates, the X8500sc allows researchers to fully image the scene and stop motion on high-speed events – whether they’re in the lab or on the test range.

• Spectral Range 1.5 – 5.0µm
• 1280 x 1024 sensor
• Framerate 181Hz – Full frame
  1280 x 1024 – 181Hz
  1280 x 512   –  352Hz
  1280 x 4 –        5362.32Hz
• Manual Focus
• Calibration -20°C to +2000°C
• 10° Lens (f =50 mm)
